WICCA Motor
1 / 4
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | ||
| RS-750H (7032R) | 6.0~12.0 | 12 VDC | 15000 | 1.79 | 12671 | 7.52 | 48.6 / 496 | 66.6 | 55.6 | 393.1 / 4010 | |
| RS-755H (7512R) | 3.0~6.0 | 6 VDC | 9500 | 2.26 | 8123 | 9.31 | 45.1 / 460 | 38.2 | 66.34 | 306.9 / 3130 | |
We are a factory specializing in producing motors for more than 14 years. With three dedicated factories, a professional R&D team, mature management, and experienced engineers, we ensure a seamless and high-quality production experience.
In order to guarantee the highest quality, every step from material sourcing to final shipment is carefully checked. Quality is the core foundation of our development.
Gold seller with established high credibility.
100% on-time delivery rate to ensure your products arrive on schedule.
Standard samples produced within 2 weeks; customized samples within 3 weeks.
Timely communication, with replies to inquiries within 2 hours.
Looking forward to your feedback!
