SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

1 / 4

SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Send Inquiry

Product Description

SRC-370SH-4730 Factory Hot selling 4.5V 17500rmp 3.63A output 11.51W

Product Description

Product specifications and details diagram

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
Model		Operating Range	Nominal	Speed (RPM)	Current (mA)	Speed (RPM)	Current (mA)	Torque (mN.m / gf.cm)	Power (W)	Current (mA)	Torque (mN.m / gf.cm)
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98 / 10	0.1	260	4.02 / 41
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4 / 24.5	1.71	2550	17 / 173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2 / 73.4	11.51	24000	55 / 561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8 / 59.2	5.17	3800	37.5 / 382.5

Click on the tilt font to know more parameters!

Application

Frequently Asked Questions

What are the primary specifications of the SRC-370SH-4730 motor?

The SRC-370SH-4730 operates at a nominal voltage of 4.5V, offering a no-load speed of 17,500 RPM, a rated current of 3.63A (3630 mA), and an output power of 11.51W.

What is the operating voltage range for the RC-370SH series motors?

Depending on the specific winding model, the RC-370SH series motors can operate within a range of 3.0V to 5.0V (for the 4730 model) or 6.0V to 12.0V (for the 18139 model).

What is the stall torque of the RC-370SH-4730 model?

The stall torque for the RC-370SH-4730 model is rated at 55 mN.m (which is equivalent to approximately 561 gf.cm).

In what applications are these PMDC motors commonly used?

These motors are versatile and commonly applied in security systems, children's toys, battery-powered appliances, micro gearboxes, and low-noise electric devices.

How does the RC-370CH compare to the RC-370SH in terms of speed and power?

The RC-370CH (nominal 6V) runs at a lower rated speed of 6,878 RPM with 1.71W output power, while the high-performance RC-370SH (nominal 4.5V) runs much faster at 15,199 RPM rated speed, delivering 11.51W of output power.
