★ Motor Customized Specification, Please contact me.
★ The length of shaft can be customized, Please contact me.
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | A | mN.m / gf.cm | ||||
| RS-770H | 8523R | 6.0~12.0 | 12 VDC | 15000 | 2.2 | 13177 | 15.91 | 81/826.2 | 111.8 | 115 | 666.9/6802 |
| RS-775H | 25110R | 6.0~24.0 | 24 VDC | 3478 | 0.15 | 2925 | 0.75 | 44.4/452.9 | 13.35 | 4.07 | 245.7/2506 |
We are a factory specialize in producing motors more than 14 years, and we have three factories. A professional R&D team, mature management, and an experienced engineering and sales team will bring you a pleasant experience.
In order to confirm quality, from the moment we receive materials to the final shipment, every step is carefully checked. Quality is the basis of our development.
We are a gold seller and in possession of high credibility.
100% on-time delivery rate to confirm your product arrives timely.
Standard samples will be produced within 2 weeks. Customized samples will be produced within 3 weeks.
Timely reply: your message will be replied within 2 hours.
